USES:
This machine is the production of cardboard core, soft paper core, such as small rolls of paper, gift paper, advertising paper, wall paper, all kinds of wrapping paper) of the special equipment.
Features:
Put the volume: rolling rack pneumatic lift
Winding: continuous gas rose axis, computer control of pneumatic and open (can be adjusted the reel diameter)
Cut off: the rodless cylinder type automatic partition back and forth
Master: microcomputer control, has accurate meter and higher automation performance
Has fixed length accuracy is high, the winding and tidy, easy operation, nice appearance, stable performance, and other functions, and can also form a complete set of automatic shrink packaging machine to form the production line.
Main Technical
Model | MW-SUA1100 |
Max Parent Roll Width | 1100mm |
Max Unwinder Diameter | 1500mm |
Max Rewinding Diameter | 200mm |
Speed | 10-150m/min |
Total | 6KW |
Machine Weight | 1300kgs |
Machine Dimension | 1500*1900*1350mm |
